3 Pole Front Panel Mount Non-Fused Switch Disconnector, 25 A, 11 kW, IP65
Product Code: R6-148
Availability: In Stock
Availability: In Stock
$24.13
Ex Tax: $24.13
Ex Tax: $24.13
Product Details
Panel Mount (Padlockable)
All switch ratings at AC22
RoHS compliant
Maximum panel thickness 3mm
Depth behind panel 102min/117max mm
Dimensions 72(H)x50(W) mm
Actuator dimensions 64x64x32mm
Approvals
UL, CSA
Specifications
Not what you’re looking for? Select the attributes you require, then click the button below
| Number of Poles | 3 | |
| Maximum Current | 25 A | |
| Mounting Type | Front Panel | |
| Power Rating | 11 kW | |
| IP Rating | IP65 | |
| Accepts Padlocks | Yes | |
| Voltage Rating | 750 V | |
| Electrical Phase | 3 | |
| Switch Rating | 6 kV | |
| Length | 125mm | |
| Width | 100mm | |
| Depth | 70mm | |
| Maximum Operating Temperature | +40°C | |
| Terminal Type | Screw | |
| Minimum Operating Temperature | -25°C | |
| Handle Colour | Red |
