3 Pole Non-Fused Switch Disconnector, 20 A, 5.5 kW, IP66, IP67
Product Code: KG10 T203/GB
Availability: In Stock
Availability: In Stock
$32.68
Ex Tax: $32.68
Ex Tax: $32.68
Product Details
Polycarbonate Enclosed Starter
High impact grey polycarbonate enclosure, UV stabilised to IP66/67
Low profile red/yellow operating handle integral with enclosure cover
Lockable with up to three padlocks in the OFF position; lid interlocked in the ON position
Earth terminal included
Nominal switching voltage 690 V
Note
Stated motor rating, Util. Cat. AC23A/AC3 is for a 3 phase 380/440 V supply.
Standards
EN60947, VDE 0660, EN 60204
Specifications
Not what you’re looking for? Select the attributes you require, then click the button below
| Number of Poles | 3 | |
| Maximum Current | 20 A | |
| Power Rating | 5.5 kW | |
| IP Rating | IP66, IP67 | |
| Accepts Padlocks | Yes | |
| Voltage Rating | 690 V ac | |
| Electrical Phase | 3 | |
| Length | 121mm | |
| Width | 86mm | |
| Depth | 107mm | |
| Maximum Operating Temperature | +55°C | |
| Handle Colour | Red/Yellow | |
| Terminal Type | Wire Lead |
