3 positions Rotary Switch, 690 V, 20 A, Knob, Stay Put
   0 reviews  |  Write a review
Product Code: 0-1-15431/E + EZ-P1
Availability: In Stock
$22.78
Ex Tax: $22.78
Product Details

Switches-22mm Single Hole or Standard Three-hole Flush Mounting

Black thumb-grip handle and silver escutcheon plate
Conform to IEC947/EN 60947
Maximum panel thickness 5mm
48 x 48mm switch front plate
Finger-proof terminals
IP65 for flush mounting three- hole mounting and IP55 for 22.5mm hole mounting (supplied with adaptor for single 22.5mm hole mounting)
Operating current: 20A
Operating temperature: –25 to +50°C

Approvals

UL, CSA

BACO/Moeller




Specifications

Not what you’re looking for? Select the attributes you require, then click the button below
Pole and Throw Configuration SP
Maximum Current 20 A
Maximum Voltage 690 V
Number of Positions 3
Width 48mm
Depth 76mm
Actuator Type Knob, Stay Put
